DB Electrical 430-22155 Marine Starter 20HP Compatible with/Replacement for Yamaha F20LPA 2012-2017, F20LPHA 2012-2017, F20PLH 2007-2011 69A-43880-01-00
4.0 (67 items)
Limited Time SaleUS$69.90 cheaper than the new price!!
Free cash-on-delivery fees for purchases over $99
Product details
| Management number | 213971440 | Release Date | 2026/04/12 | List Price | US$46.60 | Model Number | 213971440 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
**Verify the part fits before purchasing**Specs:Unit Type: Tilt & Trim MotorVoltage: 12Rotation: RETeeth: 9Dimension: Replacement Unit:, OD: 47.3mm, Shaft OD: 8.6mm , Length: 134mm, Terminal Size (2): 6.4mm, Shaft: 9-Tooth, Notes:, 42.5" Harness, Shaft Protrudes From Housing, Gear Shaft 28mm OAL (Exposed From Surface), (4) 5.8mm ID Unthreaded Mtg. Holes, Brief: Yamaha 15-20HP Outboard Motors 2001-17Replaces OEM Numbers:ARROWHEAD: 430-22155J & N: 430-22155Yamaha: 69A-43880-00-00, 69A-43880-01-00Compatible With/Replacement For:YAMAHA F15CELH 2007-2008, F15CESH 2007-2008, F15CESH 2011-2011, F15CMLH 2007-2008, F15CMSH 2007-2008, F15CPLH 2007-2008, F15CPLH 2009-2011, F15LPHA 2012-2017, F15PLH 2001-2007, F15PLR 2001-2007, F20LPA 2012-2017, F20LPHA 2012-2017, F20PLH 2007-2008, F20PLH 2009-2011, F20PLR 2007-2008, F20PLR 2009-2011
- Specs: Tilt & Trim Motor, Voltage: 12, Rotation: RE, Teeth: 9, Dimension: Replacement Unit:, OD: 47.3mm, Shaft OD: 8.6mm , Length: 134mm, Terminal Size (2): 6.4mm, Shaft: 9-Tooth, Notes:, 42.5" Harness, Shaft Protrudes From Housing, Gear Shaft 28mm OAL (Exposed From Surface), (4) 5.8mm ID Unthreaded Mtg. Holes, Brief: Yamaha 15-20HP Outboard Motors 2001-17
- Replaces OEM Numbers: ARROWHEAD: 430-22155, J & N: 430-22155, Yamaha: 69A-43880-00-00, 69A-43880-01-00
- Compatible With/Replacement For: YAMAHA F15CELH 2007-2008, F15CESH 2007-2008, F15CESH 2011-2011, F15CMLH 2007-2008, F15CMSH 2007-2008, F15CPLH 2007-2008, F15CPLH 2009-2011, F15LPHA 2012-2017, F15PLH 2001-2007, F15PLR 2001-2007, F20LPA 2012-2017, F20LPHA 2012-2017, F20PLH 2007-2008, F20PLH 2009-2011, F20PLR 2007-2008, F20PLR 2009-2011
- 1-year warranty protects you after your purchase. We're confident that our products will work flawlessly once installed in your vehicle. But in a rare case that it does not, we'll replace it anytime within one year of your order. If you have a problem, we will take every step to assist you, contact us for a replacement.
- 100% New Aftermarket Tilt & Trim Motor built to meet OEM specifications
| UPC | 713091981843 |
|---|---|
| Model | 430-22155 |
| Voltage | 12 Volts |
| Amperage | 69 Amps |
| Brand Name | DB Electrical |
| Item Weight | 2.2 Pounds |
| Part Number | 430-22155 |
| Manufacturer | DB Electrical |
| Item Dimensions | 4.25 x 4.75 x 8 inches |
| Included Components | Tilt/Trim Motor |
| Warranty Description | 1-Year Warranty |
